May 15, 2019 - Unfortunately, the CactiEZ project has been discontinued by the developer. I'll leave this HOW-TO here and perhaps someone else will be inspired to create the ISO or OVF of a new CactiEZ.

'The effort of maintaining it becomes too much in the end. Exactly why I stopped creating the CactiEZ CD.'

-----------------------

There are numerous Spicehead requests asking how to monitor and trend bandwidth utilization, and the free Cacti software can do that for you if you have a SNMP capable device, like a switch, router, or server. However, for many Spiceheads who are Windows-centric types, installing Cacti on a Linux server can be daunting.

Created by Jimmy Conner, the free CactiEZ is a great way to quickly begin using Cacti without the usual installation challenges.

I'm going to cover how to install CactiEZ and configure a Cisco router interface for monitoring.

Cactiez Iso Install Programs

8 Steps total

Step 1: Downloading

Download the CD image from http://cactiez.cactiusers.org/download/

The download is via a torrent link located in the upper right part of the web page. Some browser plugins block the torrent link. If that's the case, then try http://cactiez.cactiusers.org/torrents/CactiEZ-v0.7.torrent (I can't promise that this link will remain valid, always go to the sites download page)

Save this to a place that has at least 1GB of space. The compressed file and extracted ISO image are each around 350MB.

Step 2: Extract and Burn the CD Image

1. The ISO image must be extracted from the tar.gz file that you downloaded. Windows-centric types can use the free IZArc program from www.izarc.org
2. IZArc will ask to decompress the tar archive, select Yes.

Step 3: Install

Vista Iso Install

To install CactiEZ on a hardware, like a spare computer, you need to Burn the extracted ISO using your favorite utility.

To install CactiEZ into a Virtual Machine (VM), just use the ISO directly in your virtualization software. (e.g. VMware ESX, Workstation or Virtualbox). The CactiEZ version 0.7 ISO is based on CentOS 6 x64 (there is no 32bit version). In VMware Workstation I selected the Typical configuration and chose the option to install the operating system later. Additionally, I used an IDE drive type for the new VM.

Step 4: Installation

1. Boot from the CD and you will be prompted to press 'ENTER' to install.

WARNING: the installation will wipe the hard drive in order to install CactiEZ.

2. The installation will start. After it is done you will be prompted to remove the CD from the drive and restart the system.
3. After the system restarts, you should be able to access Cacti

Step 5: Login to Cacti

You will see the servers IP address listed above the console login. Open your web browser to http://serverip

To login to Cacti (it prompts you to change this)
user: admin
password: admin

You can access the webmin graphical management interface at https://serverip:10000
(requires the root user and password)

Iso Install Program

To login to the operating system (you should really change this)
user: root
password: CactiEZ

Step 6: Configure a Cisco Router for SNMP

There's more to the process, such as security concerns, but this will get you access to the router's SNMP information.

1. Login to the router and enter the global configuration mode
cisco# conf t

Program

2. Configure the SNMP community string
cisco(config)# snmp-server community CactiMonitoring ro
3. Save your router configuration
cisco# copy running-config startup-config

4. Document the community string, an option is to use KeePass to securely document passwords and such.

Step 7: Configure Cacti to Collect SNMP Statistics

1. Start your CactiEZ server
2. Log in to the Cacti web console on you web browser
3. Enter your Cacti admin user and password, then click Login.
4. From the Console Tab, click on Create Devices for network
5. On the right side select Add across from Devices.
6. Under General Host Options type a Description and the fully qualified Hostname or IP address. Do not click Create.
7. Under SNMP Options, choose SNMP version 2 from the dropdown list. While SNMP version 3 is more secure, and should be used whenever it is supported on the device, it is also more difficult to configure. Coulter counter service manual. I'm going to keep it simple for the sake of this HOWTO.
8. Verify that Downed Device Detection changes from Ping to SNMP. For the SNMP community type enter the string that you configured on your router.
9. Now you can click Create. Cacti will retrieve the SNMP information from the router: device uptime, location, and contact info (if you configured that information).
10. Click “Create Graphs for this Host”.
11. Under Data Query there is a list of interfaces with statistics picked up by the SNMP poll. Identify the interface that goes to the internet (or WAN), such as FastEthernet0/0, then check the box located to the right of that interface, and click Create.
12. Click Default Tree in the center under Graph Trees.
13. Click Add, located on the far right from Tree Items.
14. Under the Tree Items heading for Tree Item Type select Host in the dropdown list. For the Host item below that select the descriptive name you entered for your router. The Graphic Template should already be Graph Grouping Style. Click Create.
15. If the router was saved successfully, then it should be displayed in the list of tree items.
16. Select Devices, under Management on the left side.
17. The router should now be displayed in the list of devices monitored by Cacti. The router may initially have a status of Unknown. Wait a few minutes and check again.
18. After several minutes the router status should be displayed as Up.
19. Click the Graphs tab at the top left.
20. Under the Default Tree, click on the host name of your router.
21. It may take some time for the graph to start showing statistics, especially if there isn't much traffic going through the router interface.
22. Click on the graph, which will take you to the trended information.

I also like to graph the router CPU, memory, and interface error's.

Step 8: More Information

1. Definitely visit the CactiEZ support thread over at cacti.net: http://forums.cacti.net/viewtopic.php?f=5&t=48682 as there are some fixes that you will want to apply.

2. Read some of the Cacti User Manual, particularly the section on How to Graph your Network at http://www.cacti.net/downloads/docs/html/graph_howto.html

3. Discover how much more you can monitor and trend with Cacti in the forums at http://forums.cacti.net/

4. Visit the CactiEZ Tips page at http://cactiez.cactiusers.org/docs/tips.html

CactiEZ provides a easy way to get the Cacti program running so that you are quickly evaluating Cacti to see if it will fit your needs. CactiEZ version 0.7 was released in October 2012. Make sure you get the latest version.

VMware Workstation tip: CactiEZ version 0.7 ISO is based on CentOS 6 x64 (there is no 32bit version) operating system and VMware workstation will use an IDE drive type.

Please send Jimmy Connor some appreciation if CactiEZ works for you. Consider giving up the cost of your next fancy coffee or brew to Jimmy. There is a lot of hard work that goes into a project like this, so look for the Donations link on the CactiEZ page.

Published: Sep 10, 2011 · Last Updated: May 15, 2019

References

  • CactiEZ Support
  • CactiEZ website
  • Cacti website
  • Cisco IOS SNMP configuration
  • ImgBurn website
  • IZArc website
  • md5deep website
